Clock Chips

Description

Montage Technology offers a comprehensive suite of timing solutions, including clock generators and clock buffers. Widely used in data centers, communication, consumer, medical, and automotive electronics, these products address the industry's growing demand for high-performance clock chips.

With deep expertise in mixed-signal design, core IO technology, and PLL modules, Montage Technology incorporates advanced features such as digital architecture PLL, low-noise IO, and high power supply rejection ratio LDO into its clock chips, delivering industry-leading performance and power efficiency. Additionally, rigorous quality control and an optimized supply chain ensure superior product reliability and long-term availability.

Clock Chip

Core Advantages

  • Proprietary technology with independent IP rights
  • High performance, low power consumption
  • Ultra-low phase noise
  • Multiple independently configurable outputs
  • Wide-ranging application scenarios
  • Outstanding quality control capability

Typical Application Scenarios

CKG application 1
CKG application 2
CKG application 3
CKG application 4

Features

  • Clock Generators
    • Any frequency generation, compliant with PCIe® 6.0 specifications
    • Independent and dynamic configuration for each clock output
    • Two reference sources: on/off-chip XTAL and external clock input
    • Three user-friendly control modes: I²C, OTP, and PIN
  • Clock Buffers
    • Up to 3.1 GHz input reference clocks, with glitch-free switchover in the TBS series
    • Up to 10 differential outputs with additive RMS phase noise < 35 fs
    • Independent configuration for each output bank (IO type, voltage, and enable)
    • Excellent PSRR and ESD performance

Product List

  • Clock Generators
Part NumberInput Ref Clock (MHz)Crystal Input# of Differential Output ClocksLP-HCSLHCSLLVDSLVCMOSSupply Voltage (V)Differential Output Frequency (MHz)PackageTemperature Range (°C)Status
M88TG0104A1.22 to 250External, 8-50 MHz

4

1.8, 2.5, 3.31 to 333.3324-pin VFQFPN-40 to +85Mass Production
M88TG0104B/Internal, 50 MHz

4

1.8, 2.5, 3.31 to 333.3324-pin LGA-40 to +85Mass Production
M88TG0102A1.22 to 250External, 8-50 MHz

2

1.8, 2.5, 3.31 to 333.3316-pin LGA-40 to +85Mass Production
M88TG0102B/Internal, 50 MHz

2

1.8, 2.5, 3.31 to 333.3316-pin LGA-40 to +85Mass Production
M88TG0101A1.22 to 250External, 8-50 MHz

1

1.8, 2.5, 3.31 to 333.3312-pin LGA-40 to +85Mass Production
M88TG0101B/Internal, 50 MHz

1

1.8, 2.5, 3.31 to 333.3312-pin LGA-40 to +85Mass Production



  • Clock Buffers
Part Number*Max Input Ref ClockCrystal Input (MHz)# of Output Clock Banks# of Diff-pair per BankLVPECLLVDSLP-HCSLLVCMOSSupply Voltage (V)PackageTemperature Range (°C)Status
M88TB(S)2310A3.1 GHz8-50 251.8 - 3.348-pin WQFN-40 to +85Sampling
M88TB(S)2308A3.1 GHz8-50241.8 - 3.340-pin WQFN-40 to +85Sampling
M88TB(S)2308H1 GHz8-5024  1.8 - 3.340-pin WQFN-40 to +85Sampling
M88TB(S)2306A3.1 GHz8-50231.8 - 3.336-pin WQFN-40 to +85Sampling
M88TB(S)2304A3.1 GHz8-50221.8 - 3.332-pin WQFN-40 to +85Sampling
M88TB(S)2304H1 GHz8-5022  1.8 - 3.332-pin WQFN-40 to +85Sampling
M88TB(S)1310C350 MHz8-501/   1.5 - 3.332-pin WQFN-40 to +85Sampling
M88TB(S)2310C350 MHz8-502/   1.5 - 3.332-pin WQFN-40 to +85Sampling
M88TB(S)2205C350 MHz8-502/   1.5 - 3.324-pin WQFN-40 to +85Sampling
M88TB(S)2205M3.1 GHz8-50221.5 - 3.324-pin WQFN-40 to +85Sampling

Note: *In the part numbers, “TBS” indicates a clock buffer with glitch-free reference switchover, while “TB” denotes a clock buffer without glitch-free reference switchover .
